PLASTERING UNIT Type Kaleta – 6 230/400V
MULTIVOLTAGE
Typ. KALETA – 6S 230/400V
MULTIVOLTAGE
APPLICATION
Plastering units with possibility of single-phase power supply 230V and three phase 400V. Thanks to the possibility of switchning power supplly, thay can be used in situations where we cannot connect to a three-phase power supply or where single-phase power supply is not certain.
Thanks to this solution, the machines can be used in many ways for their intended purpose.
Used for spray applied plasters (cement-lime, lime-gypsum, gypsum, special plaster and self-leveling compounds).
EQUIPMENT
- Spray gun 1 pc.
- Mortar hose 1×10 m
- Air hose 1×10 m
- * Worm pump D6-3 FIT 1 pc.
- Mixing device 1 pc.
- Cleaner with connector 1 pc.
- Wrench for worm 1 pc.
- Gun nozzle 3 pcs.
- Open ended spanner 1 pc.
- Gun cleaner 1 pc.
- Cleaning ball 1 pc.
- Coupler g/k 2 pcs.
- Power connection adapter 1 pc.
- OMM 1 pc.
Technical characteristics
- Lenght 960 mm
- Width 670 mm
- Height 1580 mm
- Charge height 960 mm
- Weight 250 kg
- Basket capacity 100 kg
- Max output 25 l/min
- Max forcing pressure 30 atm
- *supply distance up to 20 m
- Pump motor 4 kW/230 V
- Basket motow 1,1kW/230V
- Compressor HS-24 P 300 l/min
- ¤Compressor Kaleta 250 l/min
- Water pump 230 V
- Voltage 230 V/400V 50 Hz
¤Compressor Kaleta for Plastering Unit Type KALETA – 6S/230/400V
*Possibility to use worm pump D7-2.5 FIT with increased efficiency
*Output and supply distance depend on plastering mixture and type of the pump: D or R
Cooperates with silo.
DTR
